Specification
| Engine | 150CC |
| Type | |
| BorexStroke (mm) | 62×49.5 |
| Compression | 9.0:1 |
| Output, Max(Kw/Rpm) | 8.2/8500 |
| Torque, Max(N.M/Rpm) | 9.8/7000 |
| Lgnition | CDI |
| Starting System | Electric / Kick |
| Gear and Clutch | 5-Speed |
| Drive Train | Chain |
Chassis
| Suspension/Front | Hydraulic Spring Shock |
| Suspension/Rear | Hydraulic Spring Shock |
| Brakes/Front | Disc |
| Brakes/Rear | Drum |
| Tires/Front | 2.75-18 |
| Tires/Rear | 110/90-16 |
Dimensions
| LxWxH (mm) | 1990×830×1100 |
| Wheelbase (mm) | 1310 |
| Min ground clearance (mm) | 170 |
| Net Weight (kg) | 112 |
| Max Load (kg) | 150 |
| Max Speed (km/h) | 95 |
| Climbing Ability (°) | ≥45° |
| Fuel Tank Capacity (L) | 11L |
| Fuel Type | Unleaded Gasoline With Octane No. 90 Or Higher |
| Battery | 12V7Ah |
| Quantity(40HQ) | CKD:196 sets/SKD:105 pcs (double package) |
| Price ($) | US：$ |
Color optional
| RED | BLACK | WHITE | BLUE |
Main Specification
Front disc brake and rear drum brake, round lamp, special status
